by Sihui Huang
The Decorator Design Pattern is kind of like a waffle
The decorator pattern is about adding extra features to an existing object.
Does that sound like French?
We will come back to this later.
Let’s take a look at some waffles first!
The genius part about waffles is that they start plain and simple. Because they are plain, almost everything tastes good with them
Some common toppings for waffles are strawberries, blueberries, blackberries, bananas, almonds, and syrups.
Let’s try to create a collection of different waffle objects.
There will be StrawberryWaffle, BlueberryWaffle, BlackberryWaffle, BananaWaffle, AlmondWaffle, and SyrupWaffle.
Wait, we can have strawberries and blueberries on the same waffle. This gives us a StrawberryBlueberryWaffle.
We can also have strawberries and blackberries on the same waffle. This gives us a StrawberryBlackberryWaffle.
No one is forbidding us from putting three toppings on the same waffle. This gives us a StrawberryBlueberryBlackberryWaffle.
To make things simple, let’s consider strawberries, blueberries, and blackberries as potential toppings. There are eight different combinations.
Does this mean we need to create eight different objects for our waffle collection?
If we add bananas into our potential toppings list, there are 16 different combinations.
It’s obvious that adding a single topping to our toppings list causes an explosion in our waffle collection.
It’s not feasible to create a different waffle class for each possible combination of toppings. There must be a better way to do this.
What if, when we want a StrawberryWaffle instead of creating a StrawberryWaffle, we create a Waffle and add strawberries to it?
What about StrawberryBlueberryWaffle then? ???
???We can create a Waffle, add strawberries to it, and add blueberries to it!???
Creating Waffle Classes
Let’s take a look at the plain waffle class:
You can create a waffle, serve it, and eat it like this:
And here is the StrawberryWaffle class:
Notice we pass a waffle object inside the StrawberryWaffle constructor to create a StrawberryWaffle.
The StrawberryWaffle class has:
- The passed-in waffle
- Strawberries as a topping
servemethod that calls the passed-in waffle’s
servemethod. Then prints
topped with strawberries
eatmethod that calls the passed-in waffle’s
eatmethod and then prints
and then eat some strawberries
You can create a strawberry waffle, serve it, and eat it like this:
Here are the BlueberryWaffle and BlackberryWaffle classes:
And you can use them like this:
Pulling the Common Part Out
Noticing the StrawberryWaffle class, the BlueberryWaffle class, and the BlackberryWaffle class are almost identical except for their
topping, we can pull the common parts out as a parent class.
topping is no longer an attribute of the object. Instead, it’s a method that can be overridden by a child class.
Now we can rewrite
BlackberryWaffle to inherit
WaffleDecorator to gain these common functionalities:
And they should still work the same as before:
Here are the classes we create:
Creating a BlueberryStrawberry Waffle
Now we have
It’s time to achieve the goal we originally set out:
create a Waffle, add strawberries to it, and add blueberries to it.
Just like this:
And we can:
What is happening?! ???
Let’s take a closer look at how we created the
First, we created a
plain_waffle = Waffle.new
Then we created
strawberry_waffle by passing the
plain_waffle into the
strawberry_waffle = StrawberryWaffle.new(plain_waffle)
It’s worth noting that when we create the
strawberry_waffle, we hold the passed-in
plain_waffle as an instance variable of
As we can see,
plain_waffle are the same object:
At this point, when we call
strawberry_waffle.serve. We first call
plain_waffle.serve then print
topped with strawberries.
strawberry_waffle.eat, we first call
plain_waffle.eat then print
and then eat some strawberries.
blueberry_strawberry_waffle by passing the
blueberry_strawberry_waffle = BlueberryStrawberryWaffle.new(strawberry_waffle)
When we create the
blueberry_strawberry_waffle, we hold the passed-in
strawberry_waffle as an instance variable of
When we call
blueberry_strawberry_waffle.serve we first call
strawberry_waffle.serve. Which calls
plain_waffle.serve then prints
topped with strawberries. Then print
topped with blueberries.
When we call
blueberry_strawberry_waffle.eat we first call
strawberry_waffle.eat. Which calls
plain_waffle.eat then prints and then
eat some strawberries. Then print
and then eat some blueberries.
The Key of the Magic:
strawberry_waffle is built on top of
blueberry_strawberry_waffle is built on top of
The key of being able to build waffles on top of each other is all waffles have to obey the same interface.
All waffles have a
serve method and an
That’s why within the
StrawberryWaffle/BlueberryWaffle/BlackberryWaffleclasses, we are confident that the passed-in
waffle has a
serve method and an
And we can leverage the
serve method and the
eat method from the passed-in waffle when defining a new
serve method and a new
A WaffleDecorator doesn’t care about the kind of waffle. It can be a plain_waffle, a strawberry_waffle, or an alien-waffle.
All that matters is that a WaffleDecorator takes a waffle and returns a enhanced waffle. The waffle it takes and the waffle it returns obey the same interface.
Since all decorators taking and returning waffles obey the same interface, the result of a decorator can be passed into another decorator.
Just like this:
BlackberryWaffle, we can create all eight different waffles.
Adding banana into our topping list is as easy as:
You just Learned the Decorator Pattern! ???
Here’s its definition:
Decorator attaches additional responsibilities to an object dynamically.
- The decorator pattern is about adding additional features to an existing object easily.
- The object to be decorated (the one being passed into all decorators) and objects returned from decorators have to obey the same interface.
Thanks for reading! I hope you enjoy the article. ?
I publish to sihui.io weekly.
Subscribe so you won’t miss the next article from the series.
Next time we will take a look at …
 PlainWaffle, StrawberryWaffle, BlueberryWaffle, BlackberryWaffle, StrawberryBlueberryWaffle, StrawberryBlackberryWaffle, BlueberryBlackberryWaffle, and StrawberryBlueberryBlackberryWaffle.
