by Tzahi Vidas

Here’s how I created a markdown app with Electron and React

This article is a step-by-step tutorial on how to create a basic markdown application using Electron and React.

I’ll describe why, how, and what I used to create the markdown app, which I call Mook.

The source code for Mook can be found on GitHub.

Motivation

There are a couple of reasons I started this project.

Recently, I’ve been seeing more impressive and interesting things that you can do with JavaScript. I’ve also been wanting to do something with Electron for a while now.

I had always felt weird coding with JavaScript, and, as such, avoided it. Every time I tried to do something with JavaScript, I always felt like I was just hammering on a keyboard to get whatever it was to work.

However, I recently found myself looking more into JavaScript. It suddenly felt like a good tool to use to solve some of the problems I’ve been working on.

On another note (see the pun?), whenever I use a note-taking application, I always feel like there’s a feature missing that I can find in another app. But the other app will not have the features that the third app might provide. And so I’m always on the lookout for new and better note-taking apps.

With these thoughts in mind, I decided to learn JavaScript while building a markdown notes editor with Electron.

Requirements

Some of the requirements I came up with for the markdown app are as listed.
Note that there are many more, but the following are on my initial list.

  • Editor and preview panes
  • Split screen between the editor and preview panes that can be dynamically moved
  • Support for code blocks and code language highlighting
  • Support for saving and syncing notes on GitHub
  • A hierarchy of notebooks and markdown notes
  • Support for LaTeX / math equations in the editor
  • Ability to group different notebooks with a shared topic
  • Ability to share notebooks on GitHub and on Dropbox, Google Docs and others.

The stack

I had to make a few decisions for this project. For example:

Should I use a boilerplate?

Should I use React, AngularJS, Riot, or Vue?

What kind of packages would I use?

And so on.

In the end, I decided to avoid the boilerplate approach (at least for now). I did this because I wanted to build the foundations of the app myself and learn more about it in the process.

I tried to build the app with React because I’ve heard a lot about it from friends. It appears that this is what the cool kids are using these days.

Creating the environment for the app

Because we are using React, we’ll start by creating a basic React application and then add Electron to it.

We’ll start our project using create-react-app.

Preparing the environment

An easy way to create React applications with a basic configuration is to use the create-react-app.

First, make sure that you have the latest node and npm versions on your machine. To check, run the following commands:

node -vnpm -vyarn — version

When I was writing this article, these were the versions on my machine:

node = v8.4.0npm = 5.3.0yarn = 1.0.1

Creat a React app with create-react-app

To install create-react-app as a global package, type the following command:

npm install -g create-react-app

To create a new React app and cd in it:

create-react-app mookcd mook

This is what our project looks like now. I’ve excluded the node_modules folder from view so that you can get a clear view of the project.

tree -I “node_modules”.├── README.md├── package.json├── public│ ├── favicon.ico│ ├── index.html│ └── manifest.json├── src│ ├── App.css│ ├── App.js│ ├── App.test.js│ ├── index.css│ ├── index.js│ ├── logo.svg│ └── registerServiceWorker.js└── yarn.lock
2 directories, 13 files

Now that we have a basic React app, to see what it looks like, let’s run the start script that’s defined in the package.json file:

yarn run start

That starts a new browser window with the following page:

Install Electron

Electron allows us to build an application that has the ability to run across platforms.

To install the Electron package:

yarn add electron — dev

Open the package.json file.

If everything’s OK, you should be able to see the Electron package in the devDependencies section of the file.

Update the package.json file with the following changes:

  • To add the following line to the scripts section:
“electron-start”: “electron .”
  • To add a top-level main property and point it to the main Electron file (this file doesn’t exist yet, but we will be creating it shortly):
“main”: “public/main.js”

The package.json file now looks like this:

{  “name”: “mook”,  “version”: “0.1.0”,  “main”: “public/main.js”,  “private”: true,  “dependencies”: {    “react”: “¹⁵.6.1”,    “react-dom”: “¹⁵.6.1”,    “react-scripts”: “1.0.13”  },  “scripts”: {    “start”: “react-scripts start”,    “build”: “react-scripts build”,    “test”: “react-scripts test — env=jsdom”,    “eject”: “react-scripts eject”,    “electron-start”: “electron .”  },  “devDependencies”: {    “electron”: “¹.7.6”  }}

Next, we’ll add some of Electron’s events to control the application’s life cycle. We will implement the following events:

  • ready: Runs when Electron has finished initializing. In the code, this will run createWindow, which creates a browser window with React’s local URL, http://localhost:3000, and sets the about panel and the mainWindow to null on close.
  • activate: Runs when the application is activated. We’ll want to call the createWindow function to create a new window.
  • window-all-closed: Emitted when all windows have been closed. This will close the app on all platforms, except Mac, which will only close the window but will explicitly require the user to quit the program.

Add the following code to public/main.js:

const electron = require(‘electron’);const app = electron.app;const BrowserWindow = electron.BrowserWindow;
let mainWindow;
function createWindow() {  mainWindow = new BrowserWindow({width: 900, height: 680});  mainWindow.loadURL(‘http://localhost:3000');
  app.setAboutPanelOptions({    applicationName: “Mook”,    applicationVersion: “0.0.1”,  })
  mainWindow.on(‘closed’, () => mainWindow = null);}
app.on(‘ready’, createWindow);
app.on(‘window-all-closed’, () => {  if (process.platform !== ‘darwin’) {    app.quit();  }});
app.on(‘activate’, () => {  if (mainWindow === null) {    createWindow();  }});

Make sure that React is still running in the background. If not, run it again with the following command:

yarn run start

Open a new command line window in the project’s folder and run the following command:

yarn run electron-start

After you run the command, the following window opens:

If React is not running in the background, the Electron app will open with a blank white window.

Creating a stable development and build process

Now that we have a working template for our project using Electron and React, we need to make sure that we have a stable build for development and distribution.

What we have created until now is great for development, but eventually we want to create the distribution versions of the app for OS X, Windows, and Linux.

I also didn’t like that we have to separately run the React server and Electron app in two different command line shells.

After doing some research into the topic, I found the following post, “From React to an Electron app ready for production” by @thekitze, which helped me a lot.

We will need to add the following packages to our project:

  • electron-builder — A complete solution to package and build a ready-for distribution Electron app for MacOS, Windows, and Linux with “auto update” support out of the box. We will use this package to build our app for distribution.
  • concurrently — Runs commands concurrently. We will use this package to run React and Electron concurrently in one command.
  • wait-on — Command line utility and Node.js API, which will wait for files, ports, sockets, and http(s) resources to become available. We will use this package to wait for the React server to begin running before starting the Electron app.

Run the following commands to add these packages to our app:

yarn add electron-builder wait-on concurrently — dev

Since these packages are only required for development, we will add the flag — dev to the yarn add command. This will also automatically add the packages to the devDependencies part of package.json.

Create a dev script

We want to create a development script to use while we’re building the app. This will help us test new features that we developed in the application and also to debug and make sure that we’re not breaking anything while we’re editing the code.

We’ll add a new script in the scripts section of our package.json file:

“electron-dev”: “concurrently \”BROWSER=none yarn start\” \”wait-on http://localhost:3000 && electron .\””

There are a lot of things happening in this line, so let’s break it down:

  1. concurrently” Runs the following commands at the same time.
  2. BROWSER=none yarn start” — Starts the react application and sets “BROWSER=none”. This means that the browser will not automatically open the React application.
  3. wait-on http://localhost:3000 && electron” — Waits for the development server to start. Once it’s up, it will start the Electron application.

Now, if you run the following from your command line, you will only get a single Electron application window with the React logo.

yarn run electron-dev

Create a build script

Creating the build script is a bit easier.

We need to add a couple of scripts to the scripts section in the package.json file:

  • Here is a script to build the React app before building the Electron app:
“preelectron-pack”: “yarn build”
  • Here is a script for packaging the Electron app. This script builds the application package with electron-builder.
“electron-pack”: “build — em.main=build/electron.js”

Next, we will have to specify the build property. This is because of a minor conflict between create-react-app and electron-builder. Both are using the build folder for a different purpose.

In order to solve this conflict, we need to manually configure electron-builder’s correct folders for the build step. Add the following build section to the package.json file:

“build”: {  “appId”: “com.mook”,  “files”: [    “build/**/*”,    “node_modules/**/*”  ],  “directories”: {    “buildResources”: “assets”  }}

We also need to add the homepage property to allow the packaged Electron app to find the JavaScript and CSS files:

“homepage”: “./”

At this point, your package.json file should look like this:

{  “name”: “mook”,  “version”: “0.1.0”,  “main”: “public/main.js”,  “homepage”: “./”,  “private”: true,  “scripts”: {    “start”: “react-scripts start”,    “build”: “react-scripts build”,    “test”: “react-scripts test — env=jsdom”,    “eject”: “react-scripts eject”,    “electron-start”: “electron .”,    “electron-dev”: “concurrently \”BROWSER=none yarn start\” \”wait-on http://localhost:3000 && electron .\””,    “electron-pack”: “build — em.main=build/main.js”,    “preelectron-pack”: “yarn build”  },  “dependencies”: {    “react”: “¹⁵.6.1”,    “react-dom”: “¹⁵.6.1”,    “react-scripts”: “1.0.13”,    “electron-is-dev”: “⁰.3.0”  },  “devDependencies”: {    “concurrently”: “³.5.0”,    “electron”: “¹.7.6”,    “electron-builder”: “¹⁹.27.7”,    “wait-on”: “².0.2”  },  “build”: {    “appId”: “com.mook”,    “files”: [      “build/**/*”,      “node_modules/**/*”    ],    “directories”: {      “buildResources”: “assets”    }  }}

The last step will be to update public/main.js. Until now, we’ve only supported the development version of the app. In production we won’t be able to use localhost:3000, instead we will serve the index.html file from the build folder.

First, we need to install electron-is-dev, which will help us determine if Electron is running in development.

To install the electron-is-dev package:

yarn add electron-is-dev

To update public/main.js to use electron-is-dev:

  • To add the package to the code:
const isDev = require(‘electron-is-dev’);const path = require(‘path’);
  • To change the mainWindow.loadURL functionality in the createWindow function:
mainWindow.loadURL(isDev ? ‘http://localhost:3000' : `file://${path.join(__dirname, ‘../build/index.html’)}`);

This code checks if we are in development mode, and if we are, it will use localhost:3000. Otherwise it will serve/build/index.html.

Your public/main.js file should now look like this:

const electron = require(‘electron’);const app = electron.app;const BrowserWindow = electron.BrowserWindow;const isDev = require(‘electron-is-dev’);const path = require(‘path’);
let mainWindow;
function createWindow() {  mainWindow = new BrowserWindow({width: 900, height: 680});  mainWindow.loadURL(isDev ? ‘http://localhost:3000' : `file://${path.join(__dirname, ‘../build/index.html’)}`);
  app.setAboutPanelOptions({    applicationName: “Mook”,    applicationVersion: “0.0.1”,  })
  mainWindow.on(‘closed’, () => mainWindow = null);}
app.on(‘ready’, createWindow);
app.on(‘window-all-closed’, () => {  if (process.platform !== ‘darwin’) {    app.quit();  }});
app.on(‘activate’, () => {  if (mainWindow === null) {    createWindow();  }});

Now, let’s try to run the build script with the following command:

yarn run electron-pack

When the script run is complete, you should see a new folder named dist in your project’s directory. You can find your packaged application in the folder named after your operating system. For example, Mac users will be able to find the packaged application mook.app in the dist/mac folder.

When you run that file, you should get the same screen you get for the debug version:

Excellent, we’ve just finished the build infrastructure for our app.

Adding main functionalities

Now we’re able to start adding building blocks to our markdown app.

Creating a split pane screen

Let’s start by adding the split pane component, react-split-pane, to our application.

To install the react-split-pane package:

yarn add react-split-pane

To add the following JavaScript code to the src/App.js file:

  • Import react-split-pane:
import SplitPane from ‘react-split-pane’;
  • Replace the render function with the following code. This code adds the SplitPane element to the render function with two divs, one for the editor and one for the preview pane:
render() {  return (    <div className=”App”>      <SplitPane split=”vertical” defaultSize=”50%”>        <div className=”editor-pane”>        </div>        <div className=”view-pane”>        </div>      </SplitPane>    </div>  );}

We also need to add some CSS.

To add the following code to src/App.css:

.Resizer { background: #000; opacity: .4; z-index: 1; -moz-box-sizing: border-box; -webkit-box-sizing: border-box; box-sizing: border-box; -moz-background-clip: padding; -webkit-background-clip: padding; background-clip: padding-box;}
.Resizer:hover { -webkit-transition: all 2s ease; transition: all 2s ease;}
.Resizer.horizontal { height: 11px; margin: -5px 0; border-top: 5px solid rgba(255, 255, 255, 0); border-bottom: 5px solid rgba(255, 255, 255, 0); cursor: row-resize; width: 100%;}
.Resizer.horizontal:hover { border-top: 5px solid rgba(0, 0, 0, 0.5); border-bottom: 5px solid rgba(0, 0, 0, 0.5);}
.Resizer.vertical { width: 11px; margin: 0 -5px; border-left: 5px solid rgba(255, 255, 255, 0); border-right: 5px solid rgba(255, 255, 255, 0); cursor: col-resize;}
.Resizer.vertical:hover { border-left: 5px solid rgba(0, 0, 0, 0.5); border-right: 5px solid rgba(0, 0, 0, 0.5);}.Resizer.disabled { cursor: not-allowed;}.Resizer.disabled:hover { border-color: transparent;}

If you refresh the app or run it with the command yarn run electron-dev, you should see the following screen, which is currently just an empty page divided into two panes:

You can play around with the separator bar and see how it resizes the different panes.

Creating the editor and preview panes

Now that we have our split screen, we need to add functionalities for the editor and preview panes.

We want to set up the panes like they are usually set up in markdown editors, with the editor pane on the left and the preview pane on the right. We will write our markdown in the editor pane, and the preview pane will update every time we change something in the editor pane.

Creating the editor pane

Let’s start with the editor pane.

We will use CodeMirror, which is a JavaScript text editor.

Install the React package for code mirror React-CodeMirror. Because “Code mirror value doesn’t update with state change" in React-CodeMirror, we will install @skidding/react-codemirror , which solves that issue:

yarn add @skidding/react-codemirror

Create a new file called src/editor.js, with a new class called Editor that extends React’s Component class:

import React, { Component } from ‘react’;
class Editor extends Component {}
export default Editor;

This class will basically wrap the react-codemirror package that is a React component for CodeMirror.

Next, we will import @skidding/react-codemirror and some CSS files that we want to use for the CodeMirror component, syntax highlighting, and markdown mode.

We will also add a render function that will return the CodeMirror element and add a constructor to the Editor class. This constructor allows us to initialize the CodeMirror with a value from the main file.

We’ll set the CodeMirror component to markdown mode and the theme to monokai:

import React, { Component } from ‘react’;import CodeMirror from ‘@skidding/react-codemirror’;
require(‘codemirror/lib/codemirror.css’);require(‘codemirror/mode/javascript/javascript’);require(‘codemirror/mode/python/python’);require(‘codemirror/mode/xml/xml’);require(‘codemirror/mode/markdown/markdown’);require(‘codemirror/theme/monokai.css’);
class Editor extends Component {  constructor(props) {    super(props);  }
  render() {    var options = {      mode: ‘markdown’,      theme: ‘monokai’,    }    return (      <CodeMirror value={this.props.value}  options={options} height=”100%”/>    );  }}
export default Editor;

In the src/App.js file, we will import editor.js (add to the beginning of the file):

import Editor from ‘./editor.js’;

In the App class, let’s add a constructor with an initial value for our editor:

constructor(props) {  super();
  this.state = {    markdownSrc: “# Hello World”,  }}

In the render function of the App class, add the Editor component and set the value to markdownSrc:

render() {  return (    <div className=”App”>      <SplitPane split=”vertical” defaultSize=”50%”>        <div className=”editor-pane”>          <Editor className=”editor” value={this.state.markdownSrc}/>        </div>        <div className=”view-pane”>        </div>      </SplitPane>    </div>  );}

The src/App.js file should look like this:

import React, { Component } from ‘react’;import logo from ‘./logo.svg’;import SplitPane from ‘react-split-pane’;import Editor from ‘./editor.js’;
import ‘./App.css’;
class App extends Component {  constructor(props) {    super();
    this.state = {      markdownSrc: “# Hello World”,    }  }
  render() {    return (      <div className=”App”>        <SplitPane split=”vertical” defaultSize=”50%”>          <div className=”editor-pane”>            <Editor className=”editor” value={this.state.markdownSrc}/>          </div>          <div className=”view-pane”>          </div>        </SplitPane>      </div>    );  }}
export default App;

Update the CSS file src/App.css with the following changes:

  1. In the .App section (at the top of the file), remove text-align: center; so that the text is not aligned to the center.
  2. Add the following CSS code, so that it will stretch the editor to full height and add a little padding to the right side of the text:
.editor-pane { height: 100%;}
.CodeMirror { height: 100%; padding-top: 20px; padding-left: 20px;}
.ReactCodeMirror { height: 100%;}

Refresh the app or run it with the command yarn run electron-dev, and you should see the following screen:

Creating the preview pane

We want the right pane to be a live preview of the editor that is on the left pane.

In order to do that, we will use the React-Markdown package:

yarn add react-markdown

In the src\App.js file, add the following import:

import ReactMarkdown from ‘react-markdown’;

Add the ReactMarkdown component inside the view-pane div:

<div className=”view-pane”>  <ReactMarkdown className=”result” source={this.state.markdownSrc} /></div>

Set the source of the ReactMarkdown component so that it is the same as the one in the editor, this.state.markdownSrc.

You can now run the yarn application and see the preview pane:

yarn run electron-dev

We can see the text in the preview pane. However, if we type something in the editor (left) pane, it won’t transfer to the preview (right) pane.

What we’re going to do is make every change in the editor pass to the preview, through the App class.

Adding the onMarkdownChange function to src\App.js will update markdownSrc with updated text from the editor. This function will run on every change that happens in the editor.

Add the following code to src\App.js:

constructor(props) {  super();
  this.state = {    markdownSrc: “# Hello World”  }
  this.onMarkdownChange = this.onMarkdownChange.bind(this);}
onMarkdownChange(md) {  this.setState({    markdownSrc: md  });}

In the render function, add the following to the Editor element:

<Editor className=”editor” value={this.state.markdownSrc} onChange={this.onMarkdownChange}/>

In the src/editor.js file, bind the onChange function of CodeMirror to the onChange of the parent:

constructor(props) {  super(props);
  this.updateCode = this.updateCode.bind(this);}
updateCode(e) {  this.props.onChange(e);}

In the render function, add the following to the CodeMirror element:

<CodeMirror value={this.props.value} onChange={this.updateCode} options={options} height=”100%”/>

The src/App.js file should look like:

import React, { Component } from ‘react’;import logo from ‘./logo.svg’;import SplitPane from ‘react-split-pane’;import Editor from ‘./editor.js’;import ReactMarkdown from ‘react-markdown’;
import ‘./App.css’;
class App extends Component {  constructor(props) {    super();
    this.state = {      markdownSrc: “# Hello World”    }
    this.onMarkdownChange = this.onMarkdownChange.bind(this);  }
  onMarkdownChange(md) {    this.setState({      markdownSrc: md    });  }
  render() {    return (      <div className=”App”>        <SplitPane split=”vertical” defaultSize=”50%”>          <div className=”editor-pane”>            <Editor className=”editor” value={this.state.markdownSrc} onChange={this.onMarkdownChange}/>          </div>          <div className=”view-pane”>            <ReactMarkdown className=”result” source={this.state.markdownSrc} />          </div>        </SplitPane>      </div>    );  }}
export default App;

The src/editor.js file now looks like this:

import React, { Component } from ‘react’;import CodeMirror from ‘@skidding/react-codemirror’;
require(‘codemirror/lib/codemirror.css’);require(‘codemirror/mode/javascript/javascript’);require(‘codemirror/mode/python/python’);require(‘codemirror/mode/xml/xml’);require(‘codemirror/mode/markdown/markdown’);require(‘codemirror/theme/monokai.css’);
class Editor extends Component {  constructor(props) {    super(props);
    this.updateCode = this.updateCode.bind(this);  }
  updateCode(e) {    this.props.onChange(e);  }
  render() {    var options = {      mode: ‘markdown’,      theme: ‘monokai’,    }    return (      <CodeMirror value={this.props.value} onChange={this.updateCode} options={options} height=”100%”/>    );  }}
export default Editor;

When you reload the application, you should be able to update the editor on the left with text and see the changes on the preview pane on the right.

Full source code can be found on GitHub.

What’s next?

There are still many things that we need to accomplish here:

  1. Save and open files
  2. Autosave while editing
  3. Toolbar / control over the layout of the panes
  4. Backup notes on GitHub, Dropbox and others.
  5. Support saving notes in groups or unified in a “notebook”
  6. Support math equations in Medium
  7. More amazing features!

I guess that’s what we’ll be doing next time…

Follow me on Twitter for updates about progress, upcoming features, or for any other reason.

Contributions

You can contribute in any way you want. Any help is appreciated.
Don’t hesitate to share your suggestions or comments.

Also, if you want to see a feature that you think is important, feel free to ask in the comments below or just open an issue on GitHub.
