by Andrea Bizzotto

How fast is Flutter? I built a stopwatch app to find out.

1*270WC2lY8lFF6jfPpca0WQ
Image Credit: Petar Petkovski

This weekend I had some time to play with the new Flutter UI framework by Google.

On paper it sounds great!

According to the docs, high performance is to be expected:

Flutter is designed to help developers easily achieve a constant 60fps.

But what about CPU utilization?

TL;DR: Not as good as native. And you have to do it right:

  • Frequent UI redraws are expensive
  • If you call setState() often, make sure it redraws as little UI as possible.

I built a simple stopwatch app in Flutter and profiled it to analyze CPU and memory usage.

1*Bo0l0BjIRcInHZo2ACvjsA
Left: iOS stopwatch app. Right: My version in Flutter. Beautiful, ain’t it?

Implementation

The UI is driven by two objects: a stopwatch and a timer.

  • The user can start, stop and reset the stopwatch by tapping on two buttons.
  • Each time the stopwatch is started, a periodic timer is created with a callback that fires every 30ms and updates the UI.

The main UI is built like this:

How does this work?

  • Two buttons manage the state of the stopwatch object.
  • When the stopwatch is updated, setState() is called, triggering the build() method.
  • As part of the build() method, a new TimerText is created.

The TimerText class looks like this:

A couple of notes:

  • The timer is created along with the TimerTextState object. Each time the callback fires, setState() is called if the stopwatch is running.
  • This causes the build() method to be called, which draws a new Text object with the updated time.

Doing it right

When I first built this app, I was managing all the state and UI in the TimerPage class, which included both the stopwatch and the timer.

This meant that each time the timer callback was fired, the entire UI was re-built. This is redundant and inefficient: only the Text object containing the elapsed time should be redrawn — especially as the timer fires every 30ms.

This becomes apparent if we consider the un-optimised and optimised widget tree hierarchies:

1*YrJV5E7jWzr3K0kjPBs1Mg

Creating a separate TimerText class to encapsulate the timer logic is less CPU-intensive.

In other words:

  • Frequent UI redraws are expensive
  • If you call setState() often, make sure that it redraws as little UI as possible.

The Flutter docs state that the platform is optimised for fast allocation:

The Flutter framework uses a functional-style flow that depends heavily on the underlying memory allocator efficiently handling small, short-lived allocations

Perhaps rebuilding a widget tree doesn’t count as “small, short-lived allocation”. In practice, my code optimisations resulted in a lower CPU and memory usage (see below).

Update 19–03–2018

Since publishing this article, some Google engineers took notice and kindly contributed with some further optimisations.

The updated code further reduces UI redrawing by splitting TimerText into two MinutesAndSeconds and Hundredths widgets:

1*NQxSNVJDSnZnC3DohLBTAA
Further UI optimisations (credit: Google)

These register themselves as listeners to the timer callback, and only redraw when their state changes. This further optimises performance as only the Hundredths widget now renders every 30ms.

Benchmarking results

I ran the app in release mode (flutter run --release):

  • Device: iPhone 6 running iOS 11.2
  • Flutter version: 0.1.5 (22 Feb 2018).
  • Xcode 9.2

I monitored CPU and memory usage in Xcode for three minutes, and measured the performance of the three different modes.

Non optimized code

  • CPU Usage: 28%
  • Memory usage: 32 MB (from a baseline of 17 MB after app start)
1*F1GR6mVtVEwRjaJptEuEwQ

Optimization pass 1 (separate timer text widget)

  • CPU Usage: 25%
  • Memory usage: 25 MB (from a baseline of 17 MB after app start)
1*dTO3vThMfGx0LYrLqAIlAQ

Optimization pass 2 (separate minutes, seconds, hundredths)

  • CPU Usage: 15% to 25%
  • Memory usage: 26 MB (from a baseline of 17 MB after app start)
1*JFnMDRT8utbB9C4ETPklOg

On this last test, the CPU usage graph tracks closely the GPU thread, while the UI thread stays fairly constant.

NOTE: running the same benchmark in slow mode yields CPU usage over 50%, and memory usage increasing steadily over time.

This may point to memory not being deallocated in development mode.

Key takeaway: make sure to profile your apps in release mode.

Note that Xcode reports a very high energy impact when CPU usage is over 20%.

Digging deeper

The results got me thinking. A timer which fires ~30 times per second and re-renders a text label should not use up to 25% of a dual core 1.4GHz CPU.

The widget tree in a Flutter app is built with a declarative paradigm, rather than the imperative programming model used in iOS / Android.

But is the imperative model more performant?

To find out, I have built the same stopwatch app on iOS.

This is the Swift code to setup a timer and update a text label every 30ms:

For completeness, here is the time formatting code I used in Dart (optimization pass 1):

The final results?

Flutter. CPU: 25%, Memory: 22 MB

iOS. CPU: 7%, Memory: 8 MB

The Flutter implementation is over 3x heavier on CPU, and uses 3x as much memory.

When the timer is not running, CPU usage goes back to 1%. This confirms that all CPU work goes into handling the timer callbacks and redrawing the UI.

This is not entirely surprising.

  • In the Flutter app, I build and render a new Text widget every time.
  • On iOS, I just update the text of a UILabel.

“Hey!” — I hear you saying. “But the time formatting code is different! How do you know that the difference in CPU usage is not due to this?”

Well then, let’s modify both examples to do no formatting at all:

Swift:

Dart:

Updated results:

Flutter. CPU: 15%, Memory: 22 MB

iOS. CPU: 8%, Memory: 8 MB

The Flutter implementation is still twice as CPU-intensive. Additionally, it seems to do quite a bit of stuff on multiple threads (GPU, I/O work). On iOS, only one thread is active.

Conclusion

I have compared the performance of Flutter/Dart vs iOS/Swift on a very specific use case.

The numbers don’t lie. When it comes to frequent UI updates, you can’t have your cake and eat it, too. ?

Flutter lets developers create apps for both iOS and Android with the same codebase. And features such as hot reloading further accelerate productivity. Flutter is still in its early days. I hope that Google and the community can improve the runtime profile, so that these benefits are carried over to the end-users.

As for your apps, consider fine-tuning your code to minimize UI redraws. It is well worth the effort.

I have added all the code for this project on this GitHub repo, so you can play with it yourself.

You’re welcome! ?

This sample project was my first experiment with Flutter. If you know how to write more performant code, I’d love to hear your comments.

1*TZ8Z0EnBGBugOs8mh19mHA

About me: I’m an iOS & Flutter developer, juggling between contract work, open source, side projects and blogging.

I’m @biz84 on Twitter. You can also see my GitHub page. Feedback, tweets, funny gifs, all welcome! My favorite? Lots of ???. Oh, and banana bread.
